Buy Aten CE610A-AT-U Usb Single Link Dvi Kvm Console Extender

Aten CE610A-AT-U Usb Single Link Dvi Kvm Console Extender

Delivery

In Stock
Usually ships within 24 hours*
no surcharge fee
Paypal/MasterCard/Visa/Amex
Retail Price $2,316
$1,509
Save $807
Details:The CE610A USB DVI KVM Extender is a DVI and USB Extender that supports Extreme USB ® and HDBaseT technology. The CE610A can extend DVI and USB 2.0 signals up to 300 ft (100 m) from the source using a single Cat 5e/6 cable.   The CE610A is equipped with USB connectors which allow you to extend any USB device between the units. The USB functionality provides not only peripheral sharing but also the support for touch panel control and file transfer. The CE610A is ideal for situations where touch panel is required, such as transportation centers, medical facilities, shopping malls, industrial kiosks, and when synchronizing for files / folders between portable and desktop computers are required.   Specifications: Connectors Video In 1 x DVI-D Female (White) N/A Video Output N/A 1 x DVI-D Female (White) Power 1 x DC Jack 1 x DC Jack Firmware Upgrade 1 x mini-USB 1 x mini-USB Unit To Unit 1 x RJ-45 Female (Black) 1 x RJ-45 Female (Black) USB Port 1 x USB Type B Female (White) 3 x USB Type A Female (White) LEDs Power 1 (Green) 1 (Green) Link 1 (Green) 1 (Green) USB 1 (Green) 1 (Green) Video 1 (Green) 1 (Green) USB USB 2.0 (Transfer Rate: Up to 40Mbps) USB 2.0 (Transfer Rate: Up to 40Mbps) Video 1920 x 1200 @ 60Hz (100 m) 1920 x 1200 @ 60Hz (100 m) Power Consumption DC 5V, 15 W DC 5V, 15 W Environmental Operating Temperature 0–40°C 0–40°C Storage Temperature -20–60°C -20–60°C Humidity 0–80% RH, Non-condensing 0–80% RH, Non-condensing Physical Properties Housing Metal Metal Weight 0.62 kg 0.62 kg Dimensions (L x W x H) 18.20 x 11.79 x 2.87 cm 18.20 x 11.79 x 2.87 cm
1509 1509 AUD 100
SKU
CE610A-AT-U
SKU#: CE610A-AT-U / ITEM NO: 584477 / BRAND: Aten
Rating:
$1,509.00
Shipping Calculator:
Loading...

Details:

The CE610A USB DVI KVM Extender is a DVI and USB Extender that supports Extreme USB ® and HDBaseT technology. The CE610A can extend DVI and USB 2.0 signals up to 300 ft (100 m) from the source using a single Cat 5e/6 cable.

The CE610A is equipped with USB connectors which allow you to extend any USB device between the units. The USB functionality provides not only peripheral sharing but also the support for touch panel control and file transfer. The CE610A is ideal for situations where touch panel is required, such as transportation centers, medical facilities, shopping malls, industrial kiosks, and when synchronizing for files / folders between portable and desktop computers are required.


Specifications:

Connectors
Video In 1 x DVI-D Female (White) N/A
Video Output N/A 1 x DVI-D Female (White)
Power 1 x DC Jack 1 x DC Jack
Firmware Upgrade 1 x mini-USB 1 x mini-USB
Unit To Unit 1 x RJ-45 Female (Black) 1 x RJ-45 Female (Black)
USB Port 1 x USB Type B Female (White) 3 x USB Type A Female (White)
LEDs
Power 1 (Green) 1 (Green)
Link 1 (Green) 1 (Green)
USB 1 (Green) 1 (Green)
Video 1 (Green) 1 (Green)
USB USB 2.0 (Transfer Rate: Up to 40Mbps) USB 2.0 (Transfer Rate: Up to 40Mbps)
Video 1920 x 1200 @ 60Hz (100 m) 1920 x 1200 @ 60Hz (100 m)
Power Consumption DC 5V, 15 W DC 5V, 15 W
Environmental
Operating Temperature 0–40°C 0–40°C
Storage Temperature -20–60°C -20–60°C
Humidity 0–80% RH, Non-condensing 0–80% RH, Non-condensing
Physical Properties
Housing Metal Metal
Weight 0.62 kg 0.62 kg
Dimensions (L x W x H) 18.20 x 11.79 x 2.87 cm 18.20 x 11.79 x 2.87 cm

Picture shown is for illustration purpose only
Please refer to Manufacturer SKU for the exact details
