Startech St122utpa Vga Video Extender Over Cat 5 With Audio
Picture shown is for illustration purpose only
Please refer to Manufacturer SKU for the exact details
Customer Also Bought
-
Ubiquiti UniFi Express 7 UX7
$400.00
Customer Also Viewed
Product Overview
The ST122UTPA VGA Video Extender over Cat 5 with Audio allows up to 4 (2 local and 2 remote) monitors to be connected to a single PC. The video signal and corresponding audio are sent to the remote unit over standard 4 pair Category 5 or better (Cat 5e recommended) UTP cable, supporting extended video distances of up to 150m / 500ft.
The VGA video and audio extender includes a local transmitter and a remote receiver, providing an out-of-the box solution that's perfect for point to point digital signage applications that require audio. To simplify installation, this kit also includes a mounting bracket for the ST122UTPA receiver to install onto walls, desks or cabinets for a tidy setup.
2-year warranty and free lifetime technical support.
Product Specifications
|
Warranty Information |
|
|---|---|
|
Warranty |
2 Years |
|
Hardware |
|
|
Cabling |
Cat 5e UTP or better |
|
Daisy-Chain |
No |
|
Ports |
2 |
|
Performance |
|
|
Max Distance |
150 m / 500 ft |
|
Maximum Cable Length |
500 ft [152.4 m] |
|
Supported Resolutions |
1440x900 150ft / 50m 1280x1024 300ft / 100m 1024x768 500ft / 150m |
|
Connector(s) |
|
|
Local Unit Connectors |
1 - RJ-45 Female |
|
|
1 - VGA (15 pin; High Density D-Sub) Male |
|
|
2 - 3.5 mm Mini-Jack (3 Position) Female |
|
|
2 - VGA (15 pin; High Density D-Sub) Female |
|
Remote Unit Connectors |
1 - RJ-45 Female |
|
|
2 - 3.5 mm Mini-Jack (3 Position) Female |
|
|
2 - VGA (15 pin; High Density D-Sub) Female |
|
Power |
|
|
Center Tip Polarity |
Positive |
|
Output Current |
0.6A |
|
Output Voltage |
9 DC |
|
Power Source |
AC Adapter Included |
|
Physical Characteristics |
|
|
Color |
Black |
|
Enclosure Type |
Aluminum |
|
Product Height |
0.8 in [20 mm] |
|
Product Length |
2.4 in [60 mm] |
|
Product Weight |
6.4 oz [181 g] |
|
Product Width |
3.3 in [83 mm] |
|
Packaging Information |
|
|
Shipping (Package) Weight |
2.7 lb [1.2 kg] |
|
What's in the Box |
|
|
Included in Package |
1 - Local VGA Extender Unit |
|
|
1 - Remote VGA Extender Unit |
|
|
1 - Mounting Bracket for Receiver (w/ screws) |
|
|
2 - Sets Rubber Feet |
|
|
2 - Power Adapter |
|
|
1 - Instruction Manual |
